2kg Salt Block Hydraulic Tablet Press For Cattle Deer Camel Feeding Press Machine / Salt Block Press Machine
Manual to hydraulic tablet press for research, pilot-scale and full production, presses for normal, clean-room, contained and highly contained environments and presses for the production of single and bi-layer tablets.
LISEN's strong drive to innovate and improve the compaction process is reflected in the unique design and patented features present throughout our tablet press range.
Our R&D and engineering departments constantly focus on increasing the productivity and flexibility of our tablet presses, improving tablet quality and enhancing operator safety.
Technical Parameters for Salt Block Press Machine:
| Production Capacity | 3-5molds/min(the actual speed according to product process requirement) |
| Working Pressure | ≤250T(1. step-less adjustment 2. can be bidirectional compress) |
| Working Stroke | Up stroke≤250mm,down strokes≤100mm(1. step-less adjustment 2. Customized based on customer’s request. ) |
| Filling Depth | ≤100mm(1. step-less adjustment 2. Customized based on customer’s request. ) |
| Product Mould | Customized according to the tablet features(Multi-cavity Mould) |
| Apply to Shape | Round, square, or special-shaped(suitable for a variety of shapes) |
| Motor Power | 18. 5kw 22kw(Servo) |
| Weight&Size | Approximately:5200kg 3200mm*1200mm*2100mm(L*W*H) |
Features for Salt Block Press Machine:
| Can compress 1-10kg salt licking blocks |
| Fully automatic PLC control, stable performance |
| Imported hydraulic system |
| Offer installation abroad after-sales service |
| Unique bi-layer manufacturing option |
| High sensitivity weight control for small tablets and those requiring low compression forces |
| Tablet hardness control |
| Large front and rear door for easy access |
| Complete process control |
A Salt Block Press Machine is a mechanical device that compresses powder into tablets of uniform size and weight. A tablet press can be used to manufacture tablets of a wide variety of materials, including pharmaceuticals, nutraceuticals Nutraceutical, cleaning products, industrial pellets and cosmetics. To form a tablet, the granulated powder material must be metered into a cavity formed by two punches and a die, and then the punches must be pressed together with great force to fuse the material together.
A tablet is formed by the combined pressing action of two punches and a die. In the first step of a typical operation, the bottom punch is lowered in the die creating a cavity into which the granulated feedstock is fed. The exact depth of the lower punch can be precisely controlled to meter the amount of powder that fills the cavity. The excess is scraped from the top of the die, and the lower punch is drawn down and temporarily covered to prevent spillage. Then, the upper punch is brought down into contact with the powder as the cover is removed. The force of compression is delivered by high pressure compression rolls which fuse the granulated material together into a hard tablet. After compression, the lower punch is raised to eject the tablet.
